Khumani Iron Ore Mine

                                                     BKM Project

                                           Northern Cape, South Africa

                   Soil & Dust Solutions  Dust Control  Application to Topsoil Stockpile

                              Performance Report of October 2006 – 2012 – 2016




           Visual observations and direct comparison of the 2 Topsoil stockpiles over the period October 2006 to
           February 2007 indicated that there was a marked difference between the EBS treated stockpile and the
           non  treated  topsoil  stockpile.    The  visual  indications  differentiating  the  stockpiles  are  that  the  non
           treated topsoil stockpile showed signs of wind and water erosion and less “grassing” than the treated
           stockpile.  The difference was becoming pronounced to the degree where observation from a traveling
           vehicle on the Dingleton road indicated a large and clear difference between the 2 stockpiles.

           Photographs  taken  of  the  stockpiles,  on  5  March  2007,  shown  hereunder,  clearly  indicate  the
           pronounced differences.  Working from the basis that both stockpiles were constructed in a similar
           manner and roughly the same timeframe, the degree of topsoil loss was calculated by measuring the
           current depth of the surface below protruding stone and ore aggregates.  Approximately 100 random
           measurements were made and the resultant average loss was calculated as a depth of 3,73mm.

           Assuming that the average density of topsoil is 1,640 kg/m³ and that the averaged loss of depth of the
           topsoil stockpile is uniform over the complete, non EBS treated area, that being 27 500 m² (less area
           than the topsoil stockpile treated with EBS ), the loss of topsoil over a 5 month period equates to over
           169 tons.  This equates to roughly 25 - 7 ton tipper truckloads of topsoil.  Utilising the same premise,
           if we had NOT treated the second stockpile with the EBS product, we would have lost an additional,
           230 tons of topsoil, which would have equated to some 33 - 7 ton tipper truckloads of topsoil.

           Photographs

























                      Photo #1- EBS Treated Stockpile Side Slope Showing No Signs Of Water Erosion
